Real Locksmiths. Real People. Real Jobs.
Shaun and Jayden attended a property in Cheshunt EN7 on Saturday after a homeowner contacted ASJ Locksmiths following problems with his door and handles.
The homeowner's original door handles had failed, so he purchased replacements and attempted to install them himself.
Unfortunately, the new handles didn't match the original fixing positions.
After measuring where the new fixing holes needed to be, the homeowner drilled through the door, unaware that the multipoint locking gearbox was directly behind one of those positions.
The drill went straight through the gearbox, damaging its internal components.
When Shaun and Jayden arrived, the door handle lever was stuck upside down, and the latch wasn't operating correctly.
After removing the handles and gearbox, the cause of the problem became clear.
Unfortunately, the original gearbox was no longer available as a direct replacement.
Finding a Suitable Solution
Rather than attempting to fit unsuitable parts, Shaun and Jayden took the necessary measurements and discussed the available options with the homeowner.
It was agreed that a new universal multipoint locking mechanism would be the most suitable replacement.
The work included:
✅ Damaged multipoint locking mechanism replaced
✅ Compatible replacement door handles installed
✅ Brass-finish 3-star security cylinder fitted
✅ Lock security specification upgraded
The brass cylinder was selected to complement the existing door furniture while providing an improved level of security.
Why Did a Handle Replacement Become a Much Bigger Repair?
The original problem was simply a set of failed door handles.
However, drilling additional fixing holes without checking what was behind the door resulted in damage to the gearbox.
Because the original gearbox was no longer available, the repair required a replacement multipoint locking mechanism.
What should have been a relatively straightforward handle replacement became a considerably more expensive job.
Locksmith Advice – Always Check Before Drilling
UPVC and composite door handles come in different sizes and configurations.
If replacement handles don't match the original fixing positions, don't assume drilling new holes is the solution.
Older doors may require specialist or adjustable replacement handles.
Before making alterations, it's essential to check the measurements, compatibility and position of the locking mechanism.
A few minutes checking the correct replacement could prevent costly damage.
Another genuine UPVC door repair and multipoint locking mechanism replacement in Cheshunt EN7, completed by Shaun and Jayden of ASJ Locksmiths.
ASJ Locksmiths – Real Locksmiths. Real People. Real Jobs.
